Products & Technology
EXCELLENCE IN PHOTONICS
SuperLight Photonics offers world’s first
portable wideband laser, the SLP-1000
SuperLight Photonics, specialist in supercontinuum lasers, has developed the first revolutionary portable wideband laser, the SLP-1000.
Its high-quality smooth wide spectral output offers an unrivalled light source for a wide range of industrial and bio-medical imaging applications and for the dynamic world of spectroscopy.
INTERESTED?
Send your datasheet request through the form below
More power, more light, better insight
The SLP-1050 redefines high-end supercontinuum lasers
To address the increasing demand for high-power and compact supercontinuum laser (SCG or wideband laser) solutions, SuperLight Photonics has released its second generation product, the SLP-1050, harnessing unprecedented power for enhanced industrial, research, and (bio)medical applications.
Using an amplified seed laser, this supercontinuum laser is designed to deliver more than 40 mW - more than 15 times the battery-operated SLP-1000 - and a wide spectral range in the NIR-SWIR region. Just like the SLP-1000, it provides a highly coherent, stable, and low noise output.
NEW
The SLP-0280, the world’s first of its kind compact ultrafast pulse laser
The SLP-0280 is an ultrafast laser delivering 25 femtosecond pulses with a center wavelength of 1750 nm (+/- 200 nm).
SuperLight Photonics’ unique and patented PAD – Patterned Alternating Dispersion ™ technology is leveraged, applying non-linear pulse compression in a highly efficient way. The resulting 25 fs pulses are obtained with substantially lower pulse energy than traditionally needed for such pulse compression. Based on a photonic integrated circuit (PIC) platform, the form factor is substantially reduced compared to similar lasers.
The SLP-0280 outperforms traditional complex systems, and it sets a new benchmark as an ultrafast, low noise, ultra-stable, small form factor laser solution. It is designed to excel in both scientific and industrial applications.
Key Product Features
-
PIC-based supercontinuum generation
-
PAD - Patterned Alternating Dispersion™
-
Class 3 laser safety
-
Short start-up time
-
No need for calibration, high uptime, maintenance-free
-
Compact form factor, low weight & robust
SLP-1000 Features
-
Highly efficient spectral broadening
-
Wide, smooth, and low noise spectral output (SWIR)
-
Short pulse width, high peak power
-
Ultra low power consumption
-
Portable & battery operated
SLP-1050 Features
-
Femtosecond pulse laser
-
Highly efficient spectral broadening
-
Amplified seed laser increases output power & spectral range
-
Wide, smooth, and low noise spectral output (SWIR)
-
Short pulse width, high peak power
-
Compact form factor
SLP-0280 Features
-
Ultrafast, low noise
output, ultra-stable -
Ultrashort pulse lengths in a compact form factor
An industry first! -
Applying efficient non-linear PIC-based pulse compression
SuperLight Photonics proudly answers
the industry demand for a
compact, high-quality wideband laser
PAD - Patterned Alternating Dispersion ™ Mechanism
Developed to overcome the limitations of traditional supercontinuum lasers
Explaining the SuperLight Photonics' PAD - Patterned Alternating Dispersion™ mechanism,
with pulse compression for spectral broadening.
SLP-1000 | SLP-1050 | SLP-0280 | |
|---|---|---|---|
Industry-first portable & battery operated SCG | Unprecedented high-power & compact SCG | Compact & ultrafacst pulse laser | |
Product Features | SLP-1000 | SLP-1050 | SLP-0280 |
Avg Output Power | 3 mW | 50 mW | 50 mW |
Peak Output Power | 1.5 kW | 25 kW | 25 kW |
Pulse Energy | 30 pJ | 500 pJ | 500 pJ |
Spectral Range (-3dB) | 400 nm (1450-1950 nm) | 900 nm (1550–2450 nm) | 1750 nm +/- 200 nm) |
Pulse Length | 25 fs @ 100 MHz | 25 fs @ 100 MHz | 25 fs @ 100 MHz |
Amplitude Stability | 0.5% RMS over 24 h | 0.5% RMS over 24 h | 0.5% RMS over 24 h |
Relative Instensity Noise | -140 dB/Hz | -120 dB/Hz | -120 dB/Hz |
Laser Security | Class IIIb | Class IIIb | Class IIIb |
Power Supply | Battery & DC/AC | DC/AC | DC/AC |
Startup Time | < 60 s | < 60 s | < 60 s |
Weight-Volume | 1 kg - 1 l | 1.2 kg - 1 l | 1.2 kg - 1 l |
Do you like what you just read? Request the preliminary datasheets through the form below.
